REQUEST QUOTATION FOR SPECIAL (Click here)
Benefits:
- Ergonomically designed
- Plug and play/user-friendly
- Rugged & reliable inspection tool
- Seven standard mounting options
- Stand alone system (no computer needed)
- Eye or safety glasses can be worn during use
- Made with aerospace aluminum and cutting-edge technology
Features:
- Parfocal over entire zoom range
- Great depth of field & large field of view
- Ring light provides shadow free illumination
- 16×9 HD image aspect ratio displayed @ 60fps
- Extends up to 30” horizontal/ 18” vertical range
- Easily positioned to provide many viewing angles
- High resolution video optics with 10:1 zoom ratio
| Optical Magnification with 24” Monitor | 3X – 90X (Standard) |
| 6X – 180X (Optional w/110-12) | |
| Large Working Distance | 6” – 12” (Standard) |
| 6” – 18” (Optional w/250-04) |
Accessories
PRO220 Video Inspection System Accessories
| Part # | ||
| 110-12 | Extender Lens | 2X extender lens doubles the focal length |
| 150-12 | Polarizer Lens | Removes reflective incident light |
| 250-04 | 6” Extension | Extension for articulating arm |
| 318-01 | LED Dual Spot Light | Adjustable LED light for use with articulating arm |
| VA7 | HDMI/USB 3 Converter | Imaging capture device and measurement software |
